Rod Mill

Feeding size: ≤25-≤50mm

Processing capacity: 0.62-180t/h

Processible materials: all kinds of minerals and other materials.

Application range: metallurgy, mining, chemical engineering, coal, refractory matter and ceramic production.

Advantages: even product granularity, few over crushing particles, long service life.

Get a Quotation Leave Message
You can also contact with us by:

Overview

Rod mill is also called rod grinding rod mill, bar mill and rod grinding mill. Our rod grinder is especially suitable for crushing river gravel to make sand. It's a kind of effective and energy saving rod grinding machine. Moreover, according to different materials and discharging methods, there are dry rod mills and wet type rod mills for choice. We can make the rod mill according to the different commendation of the customers, whose satisfaction can be our great honor in the process of production. Today let us have the honor to introduce the basic information to the people looking for it.

The rod grinding mill has two types, one is wet type rod mill and the other is dry rod mill, which has been told in the past, and the two types grinding mills have the advantages that cannot be caught up with so easily by others, such as high efficiency, high production capacity, the large output and the uniform granularity.

In some cases, rod mill can replace short head cone crusher and do finely grinding. When dealing with softer or ore that is not too hard (especially the ore is with big viscosity), rod milling will grind the ore from 19-25 mm (or even 32 mm) to 6-10 mm, with lower cost and a simpler device compared with short head cone crusher. And can also make the workshop dustless and simplified.

Technical Data

Model
Shell Specifications (mm)
Shell rotation speed
(r/min)
Feeding size
(mm)
Discharging size
(mm)
Processing capacity
(t/h)
Power
(kw)
Total weight
(t)
Diameter Length
MBS0918 900 1800 36-38 ≤25 0.833-0.147 0.62-3.2 18.5 5.9
MBS0924 900 2400 36 ≤25 0.833-0.147 0.81-4.3 22 6.7
MBS1224 1200 2400 36 ≤25 0.833-0.147 1.1-4.9 30 13.9
MBS1530 1500 3000 29.7 ≤25 0.833-0.147 2.4-7.5 75 19.8
MBS1830 1830 3000 25.4 ≤25 0.833-0.147 4.8-11.6 130 34.9
MBS2130 2100 3000 23.7 ≤25 0.833-0.147 14-35 155 46.5
MBS2136 2100 3600 23.7 ≤25 0.833-0.147 19-43 180 48.7
MBS2430 2400 3000 21 ≤50 0.833-0.147 25-65 245 59.7
MBS2736 2700 3600 20.7 ≤50 0.833-0.147 32-86 380 92.5
MBS2740 2700 4000 20.7 ≤50 0.833-0.147 32-92 400 95
MBS3245 3200 4500 18 ≤50 0.833-0.147 64-180 630 149
